ACT LWT DTNVS ECHO White Phosphor

7 700.00

ACT DTNVS Photonis ECHO White Phosphor, FOM 1600-2000, Autogated. Ultralight RPO Optics

FREE Shipping

This item: ACT LWT DTNVS ECHO White Phosphor
7 700.00
7 700.00
Original price was: €2 550.00.Current price is: €2 422.50.
Original price was: €625.00.Current price is: €593.75.
Original price was: €575.00.Current price is: €546.25.
2 × Infinity Iris V1 - Black

In stock

Original price was: €195.00.Current price is: €185.25.
S&S Precision Manta Strobe
1 × S&S Manta Strobe™

In stock

Original price was: €229.17.Current price is: €217.71.
7 700.00
Unit 1235D
Clear selection
GTIN: N/A SKU: DTNVS-14-LWT40-ZW0124B Categories: , Tags: , ,

Description

1235D

LEFTRIGHT
FOM19301966
Resolution6767
EBI0,170,15
SN28,8129,35
Gain92609144
Price7700€+ VAT

The DTNVS is a lightweight folding binocular built on proven technology and enhanced for greater reliability verse previous generations of Night Vision Binoculars. The DTNVS binocular combines lightweight materials and a low profile when folded to the helmet which reduces neck strain during extended missions.

The DTNVS binocular has a full feature set with individual sideways ON/OFF for each eyepiece and Flip-Up ON/OFF when folded up preventing backsplash on the helmet. To complete the DTNVSs’ features it incorporates built-in IR LED for close quarter missions with separate IR-ON indicator and low battery indicator in the field of view.

No external battery port – Why? The DTNVS uses standard CR123A batteries as commonly found in lasers or flashlights. A single battery provides over 25h run time. However, as the pods shut off when flipped up and therefore halve the power consumption, most users report up to 35h on a single battery.

Image Intensifier Tubes (IIT)Photonis ECHO White Phosphor
FinishMatte Black, Corrosion Resistant
Fibre re-enforces polycarbonate body
CapabilityFlip-Up On-Off
Side Flip-Up On-Off
Built-in IR LED with “IR-on” indicator in FOV
Low battery indicator in FOV
Waterproof: 20m (66ft) for 2 hours
Corrosion Resistance against salt water
Magnification1x
Diopter compensation-6 to +2 dpt
Battery Life25 h
Infrared illuminatoryes
StandardsExceeding MIL-STD-810G
True field of view40°
Close focus limit0.25 m to ∞
Power Supply1x CR123
Dimensions76 x 105 x 111 mm
Weight510 g
Included accessories
  • Hardcase
  • Molle pouch
  • Sacrificial lenses
  • Demist shields
  • Protective bikini covers
  • Rubber eye-cups
  • Objective lens caps
Included paperwork (original documentation is always included)
  • Tube specification sheet
  • Device birth certificate
  • Falconclaw user manual
  • Merchandise (patches, ACT lens cleaning paper)
  • Note! Flip the hardcase top cover foam to find everything above

Additional information

DTNVS ECHO WP Tube

1235D

Brand

ACT

From 2013 ACTinBlack (ACT) was founded out of the drive to develop better, lighter and more user focused night vision systems – together with users from across the globe. The introduction of the DTNVG in 2016 created a (now) classic night vision binocular that proved itself in the harshest environments. To add to its legacy the introduction of the successor, the DTNVS, in 2020 created a milestone to ACT’s product line with a product that found immediate success by military and law enforcement user across the world. See more at https://actinblack.com/us/
