FC-BR 1800+ FOM White Phosphor
FC-BR 1800+ FOM White Phosphor
Sale price€6.968,80 EUR
Serial-matched inventory
Available Units
Every tube: NNVT 1800+ White Phosphor · autogated · individually data-sheeted
LRSold outFalconclaw - FC-BR 1800
Both eyes open
A dual-tube white-phosphor binocular on autogated 1800+ FOM tubes. Aerospace-grade 7075 aluminum, around 450 g, with each eye looking through its own intensifier - so you keep depth perception and stereo vision in full dark.
Built for the field
Why the FC-BR 1800
A binocular, not a monocular. Two independent pods, each on its own white-phosphor tube, so depth perception and stereo vision hold up in the dark. Aerospace-grade 7075 aluminum housing, individual pod shut-off, autogated 1800+ FOM tubes - the entry into the FC-BR line.
Dual-tube binocular
Two independent intensifier pods, one per eye. Stereo night vision with real depth perception, not a flat single-tube image.
7075 aluminum housing
Aerospace-grade 7075 aluminum body. Around 450 g, 83 x 104 x 104 mm, and lighter than most dual-tubes despite the stronger material.
Individual pod shut-off
Rotate a pod 90 degrees and it powers off on its own. Run one eye to save the tube and your dark adaptation.
Auto-gating
Autogated tubes hold a clean image through muzzle flash, headlights and other bright sources, no manual gain fumbling.
1800+
Tube FOMNNVT White Phosphor
40°
Field of viewtrue, 1x magnification
450 g
Weight7075 aluminum housing
1 x
Magnificationtrue 1:1 view
The numbers
Product Specs
Optics & Sensor
Image Intensifier Tubes (IIT)NNVT 1800+ FOM (White Phosphor)
Magnification1x
True Field of View40°
Close Focus Limit0.25 m to ∞
Diopter Compensation-6 to +2 dpt
Performance
AutogatingYes, protects tubes in bright light
Infrared IlluminatorNo
Individual pod shut-offYes
Power & Battery
Power Supply1x CR123 onboard
Battery Life[TODO: confirm - Woo data missing]
Build & Durability
Finish7075 Aluminum
Dimensions83H x 104W x 104L mm
Weight450 g
Build your kit
Compatibility
An FC-BR is already binocular - it mounts straight to a UDAPT helmet mount, no J-arm needed.
Build it as a kit and the add-ons come off automatically: -20% on every mount, bridge and adapter, -10% on a second optic. Applied in your cart, no code.
The dovetail on the housing drops the FC-BR to eye level on a UDAPT F25 mount. Run it solo, or add the FTO 640 thermal overlay to fuse heat onto the night-vision image.
STANDALONE
Your STANDALONE build
Parts you need to add
The FC-BR on the helmet via a UDAPT F25 mount. Passive, lightweight, binocular depth out of the box.
udapt
UDAPT F25 Low Profile Helmet Mount
Sale price€434,00 EUR
THERMAL OVERLAY - COTI
Your THERMAL OVERLAY - COTI build
Parts you need to add
Clip the FTO 640 thermal overlay onto the FC-BR to fuse heat detection over the night-vision image. Spot warm targets the tubes alone miss.
.%20Autogated%20NNVT%201800+%20tubes.%20Aerospace-grade%207075%20aluminum%20housing.%20450%20g.
){kind=link}
Infiray
FTO Falconclaw Thermal Overlay 640 (COTI)
Sale price€3.899,80 EUR
udapt
UDAPT F25 Low Profile Helmet Mount
Sale price€434,00 EUR
Every order
What's in the Box
Box contents · 7 items
- FC-BR unit factory collimated
- Hardcase
- Bikini covers
- Daycaps
- Tube specification sheet
- Birth certificate
- Falconclaw user manual
No helmet mount included a FC-BR mounts straight to a dovetail helmet mount (no J-arm) - see the kit options above
Export control
Shipping & Export
This item is shipped
EU - SHIPS FREELY, ZERO PAPERWORKAll 27 EU countries. Order online, we dispatch next business day.
Ships free
EU001 - WE HANDLE EXPORT, YOU HANDLE IMPORTUK, Norway, Switzerland, Liechtenstein, Iceland, Canada, Australia, New Zealand, Japan. Dispatched under EU General Authorisation EU001.
We export
OTHER COUNTRIES - EXPORT LICENCE REQUIREDIndividual export licence to most other destinations (+€250). Contact us first.
Licence +€250
NOT AVAILABLE TO THE UNITED STATESWe cannot ship the FC-BR 1800+ FOM White Phosphor to the USA.
No US shipping
