InfiRay MH-25W Thermal Imager

2 988.00

InfiRay MH-25W Thermal Imager with 640×512 50hz thermal sensor, 30mK. Weighs only 340g. Helmet mountable.

Out of stock

Email when stock available

GTIN: N/A SKU: IRAY-MH25W Category:

Description

Mini II MH25W is a multifunction thermal imager with built-in VOx uncooled infrared focal plane array detector. Mini II series has small size, light weight, high performance, various purpose and many other strengths. Moreover, a variety of sensors are equipped and it not only can be used as Monocular hand-held thermal imager or portable infrared thermal image sight but also can be used as wearable device when installed on the helmet. Mini II series can be widely used in investigation, security, search and rescue, outdoor sports and other application fields.

System functions:

  • Image calibration:Background calibration/Shutter calibration
  • Image mode: Black hot/White hot/Red hot/Pseudo Color
  • Image brightness/sharpness adjustment
  • Motion sensor adjusts the forward image
  • Picture in picture
  • Automatic standby
  • Supply power and transmitting data through Type-C interface
  • Reticle and Laser function

Legal disclaimer: Falconclaw OÜ is not responsible for any restrictions you might have in your county regarding this device. The buyer is responsible for understanding the law in his/her country.

M6
IMG_20210319234706

Detector 640 x 512 /12um
Lens f25mm
Human recognition 1000m
Vehicle recognition 1298 m
NETD ≤30mK
Frame rate 50Hz
FOV 17.6°x13.2°
Objective Lens 25mm
Laser pointer Yes
Diopter compensation -5 to +5 dpt
Optical zoom 1x
Electonic zoom 1 – 4x
Battery life ≥ 2h / 4.5h
Battery type 1x CR123 3,7V/ With extender 1×16650 (Rechargeable battery)
Display 1024×768 AMOLED
Built-in memory 32gb
Recoil proof No
Mounting options Handheld, Helmet, Weapon
Weight 340g
Dimentsions 128 x 70 x 45 mm
IP raiting IP66
Operating temperature -20°C to + 50°C
Storge temperature -20°C to + 50°C
Other characteristics
  • Shuttered and manual calibration
  • Reticle and laser feature
  • Variety of Power Supply Options (USB-C)
  • Supports photographing and video recording
Included accessories
  • Soft carry-on case
  • Data cable
  • Remote control
  • 18650 battery extender
  • Picatinny mount

Brand

InfiRay
