Infiray E6+ Thermal Monocular V3.0

2 548.80

Thermal Imager 640×512 50hz, 35mm objective lens, internal battery, NETD≤25mk, internal recording, WiFi.

In stock

GTIN: N/A SKU: IRAY-E6PLUSV3 Category:

Description

Meet Infiray  thermal imaging monocular EYE IIV3(E6+V3 and E6PROV3) which imaging quality has come to a new level with excellent performance12um 640 resolution thermal imaging sensor featuring NETD≤25mK(@25 °C,F#=1.0) and richly contrast 1024*768 resolutions OLED integrated display. Better sensor, clearer imaging!

System functions:

  • Image calibration:Background calibration/Shutter calibratiom
  • Image mode: Black hot/White hot/Red hot/Pseudo Color
  • Image brightness/sharpness/contrast adjustment
  • Motion sensor adjusts the forward image
  • Dip measurement
  • Probability rangefinder
  • Picture in picture
  • Automatic standby
  • Supply power and transmitting data through Micro-USB interface
IMPORTANT: This product cannot be used as thermal sight. It’s not certified to be mounted on a firearm and does not withstand the recoil. Hand-held or helmet-mountable only.
FP-BigTitle-E6

Detector 640 x 512 /12um
Lens f25mm
Human recognition 1818 m
Vehicle recognition 1818 m
NETD ≤25mK
Frame rate 50Hz
FOV 12.5°x10°
Objective Lens 35mm
Laser pointer Yes
Diopter compensation -4 to +3 dpt
Optical zoom 2x
Electonic zoom 1 – 4x
Battery life ≥ 6h
Battery type Internal battery
Display 1024×768 OLED
Storage 32 GB
Recoil proof No
Mounting options Handheld
Weight 420 g
Dimentsions 188 x 65 x 64 mm
IP raiting IP67
Operating temperature -10°C to + 50°C
Storge temperature -10°C to + 50°C
Other characteristics
  • Shuttered and manual calibration
  • Stadiametric Rangefinder
  • Inclinometer and E-Compass
  • Long distamce detection
  • 5 color palettes
  • 32GB internal storage and Wifi connection
