ACT MUM14 ECHO GP

4 134.005 004.00

Photonis Autogated ECHO Green Phosphor night-vision device. J-arm and sac lens included. FOM between 1600 and 2000.

4 134.005 004.00
MUM14 GP ECHO A001914 A001915 A001917 A001919 A001922
Clear selection
GTIN: N/A SKU: MUM-ZG0124B Category: Tags: , ,

Description

Available models

Since the difference between units can be pretty big (both FOM and the existence of black spots), we have decided to make public units specification and picture of the tube (to see black spots). Price depends on the quality of the tube. Please be aware that not all spots are visible on those pictures and in real life the spots appear to be bigger than on this picture. Spots score is our own metric to compare visibility of spots between tubes.

A001914

FOM 1979
Gain 12790
Resolution 68
EBI 0.15
SN 29.10
IA 0.07
Price 4170€ + VAT

A001915

FOM1783
Gain12662
Resolution72
EBI0.11
SN24.76
IA0.10
Price3525€ + VAT

A001917

FOM1955
Gain12457
Resolution82
EBI0.19
SN23.84
IA0.11
Price3445€ + VAT

A001919

FOM1768
Gain12373
Resolution68
EBI0.14
SN26.00
IA0.16
Price3550€ + VAT

A001922

FOM1913
Gain12962
Resolution69
EBI0.15
SN27.72
IA0.09
Price3985€ + VAT
Housing

The MUM-14 Mini-monocular is small and versatile high perfoming system in a small tough package.

Extremely lightweight and versatile, the MUM-14 can be hand-held, head-mounted, helmet-mounted, camera/camcorder adapted or weapons mounted, which enables night vision capabilities to daytime optical sights.

The MUM-14 has a 66ft / 20m submersion rating.

MUM-14 is not compatible to all PVS-14 type accessories, and utilises MINIRAIL for mounting options.

Image Intensifier Tube

Photonis ECHO GP ZG0124B FOM range 1600-2000.

Image Intensifier Tubes (IIT)Photonis ECHO Green Phosphor
CapabilityBuilt-in IR LED with “IR-on” indicator in FOV
Low battery indicator in FOV
Waterproof: 20m (66ft) for 2h
Autogating
Magnification1x
Diopter compensation-6 to +2 dpt
Battery Life40 h CR123 / 20H AA (battery adapter included)
Infrared illuminatoryes
StandardsExceeding MIL-STD-810G
True field of view40°
Range of focus0.25 m to ∞
Power Supply1x AA or 1x CR123
Dimensions108 x 69 x 50 mm
Weight260 g
Included accessories
  • Hardcase
  • Minirail J-Arm (Bayonet)
  • Sacrificial lens
  • Demist shield
  • Rubber eye-cup
  • Objective lens cap
  • Battery adapter (conversion from CR123 battery to AA)
Included paperwork (original documentation is always included)
  • Tube specification sheet
  • Device birth certificate
  • Falconclaw user manual
  • Merchandise (patches, ACT lens cleaning paper)
  • Note! Flip the hardcase top cover foam to find everything above

Brand

ACT

Additional information

MUM14 GP ECHO

A001914, A001915, A001917, A001919, A001922
