Description
0874E
 |  |
| LEFT | RIGHT | ||
| FOM | 2122 | 2146 | |
| Resolution | 76 | 76 | |
| EBI | 0,11 | 0,17 | |
| SN | 27,92 | 28,24 | |
| Gain | 10 033 | 10 198 | |
| Price | 8050€+ VAT | ||
1102E
 |  |
| LEFT | RIGHT | ||
| FOM | 2084 | 2105 | |
| Resolution | 78 | 78 | |
| EBI | 0,19 | 0,17 | |
| SN | 26,72 | 26,99 | |
| Gain | 10 454 | 10 465 | |
| Price | 7875€+ VAT | ||
1107E
 |  |
| LEFT | RIGHT | ||
| FOM | 1944 | 1907 | |
| Resolution | 64 | 67 | |
| EBI | 0,16 | 0,16 | |
| SN | 30,37 | 28,47 | |
| Gain | 10 664 | 10 586 | |
| Price | 7950€+ VAT | ||
1101E
 |  |
| LEFT | RIGHT | ||
| FOM | 1812 | 1854 | |
| Resolution | 67 | 67 | |
| EBI | 0,12 | 0,12 | |
| SN | 27,05 | 27,67 | |
| Gain | 10 717 | 10 569 | |
| Price | 7800€+ VAT | ||
1103E
 |  |
| LEFT | RIGHT | ||
| FOM | 2161 | 2056 | |
| Resolution | 76 | 76 | |
| EBI | 0,15 | 0,22 | |
| SN | 28,44 | 27,05 | |
| Gain | 10 236 | 10 405 | |
| Price | 7975€+ VAT | ||
1104E
 |  |
| LEFT | RIGHT | ||
| FOM | 1971 | 1988 | |
| Resolution | 66 | 66 | |
| EBI | 0,04 | 0,08 | |
| SN | 29,86 | 30,12 | |
| Gain | 10 662 | 10 554 | |
| Price | 7820€+ VAT | ||
1235D
 |  |
| LEFT | RIGHT | ||
| FOM | 1930 | 1966 | |
| Resolution | 67 | 67 | |
| EBI | 0,17 | 0,15 | |
| SN | 28,81 | 29,35 | |
| Gain | 9260 | 9144 | |
| Price | 7755€+ VAT | ||
1109E
 |  |
| LEFT | RIGHT | ||
| FOM | 2100 | 2060 | |
| Resolution | 67 | 66 | |
| EBI | 0,12 | 0,16 | |
| SN | 31,34 | 31,21 | |
| Gain | 10 598 | 11 037 | |
| Price | 7990€+ VAT | ||
1106E
 |  |
| LEFT | RIGHT | ||
| FOM | 1961 | 1989 | |
| Resolution | 66 | 66 | |
| EBI | 0,16 | 0,10 | |
| SN | 29,71 | 30,13 | |
| Gain | 10 794 | 10 242 | |
| Price | 7850€+ VAT | ||
1111E
 |  |
| LEFT | RIGHT | ||
| FOM | 1884 | 1880 | |
| Resolution | 66 | 67 | |
| EBI | 0,14 | 0,14 | |
| SN | 28,55 | 28,06 | |
| Gain | 10 172 | 10 537 | |
| Price | 7835€+ VAT | ||
The DTNVS is a lightweight folding binocular built on proven technology and enhanced for greater reliability verse previous generations of Night Vision Binoculars. The DTNVS binocular combines lightweight materials and a low profile when folded to the helmet which reduces neck strain during extended missions.
The DTNVS binocular has a full feature set with individual sideways ON/OFF for each eyepiece and Flip-Up ON/OFF when folded up preventing backsplash on the helmet. To complete the DTNVSs’ features it incorporates built-in IR LED for close quarter missions with separate IR-ON indicator and low battery indicator in the field of view.
No external battery port – Why? The DTNVS uses standard CR123A batteries as commonly found in lasers or flashlights. A single battery provides over 25h run time. However, as the pods shut off when flipped up and therefore halve the power consumption, most users report up to 35h on a single battery.
| Image Intensifier Tubes (IIT) | Photonis ECHO White Phosphor |
| Finish | Matte Black, Corrosion Resistant Fibre re-enforces polycarbonate body |
| Capability | Flip-Up On-Off Side Flip-Up On-Off Built-in IR LED with “IR-on” indicator in FOV Low battery indicator in FOV Waterproof: 20m (66ft) for 2 hours Corrosion Resistance against salt water |
| Magnification | 1x |
| Diopter compensation | -6 to +2 dpt |
| Battery Life | 25 h |
| Infrared illuminator | yes |
| Standards | Exceeding MIL-STD-810G |
| True field of view | 40° |
| Close focus limit | 0.25 m to ∞ |
| Power Supply | 1x CR123 |
| Dimensions | 76 x 105 x 111 mm |
| Weight | 510 g |
Included accessories
- Hardcase
- Molle pouch
- Sacrificial lenses
- Demist shields
- Protective bikini covers
- Rubber eye-cups
- Objective lens caps
Included paperwork (original documentation is always included)
- Tube specification sheet
- Device birth certificate
- Falconclaw user manual
- Merchandise (patches, ACT lens cleaning paper)
- Note! Flip the hardcase top cover foam to find everything above
