ACT LWT DTNVS GEN3 White Phosphor

15 060.0015 792.00

ACT DTNVS Harder Gen3 White Phosphor, FOM 2000, Lightweight optics, Autogated

FREE Shipping

15 060.0015 792.00
Unit 0280D 0281D 0283D 0284D
Clear selection
GTIN: N/A SKU: DTNVS-14-LWT40-HD20AGWP Category: Tags: ,

Description

0280D

LEFTRIGHT
FOM20812066
Resolution7272
EBI0,91,1
SN28,928,7
Price13 160€ + VAT

0281D

LEFTRIGHT
FOM20742066
Resolution7272
EBI1,01,1
SN28,828,7
Price12 580€ + VAT

0283D

LEFTRIGHT
FOM21022059
Resolution7272
EBI0,81,0
SN29,228,6
Price12 790€ + VAT

0284D

LEFTRIGHT
FOM20812016
Resolution7272
EBI1,00,7
SN28,928,0
Price12 550€ + VAT

The DTNVS is a lightweight folding binocular built on proven technology and enhanced for greater reliability verse previous generations of Night Vision Binoculars. The DTNVS binocular combines lightweight materials and a low profile when folded to the helmet which reduces neck strain during extended missions.

The DTNVS binocular has a full feature set with individual sideways ON/OFF for each eyepiece and Flip-Up ON/OFF when folded up preventing backsplash on the helmet. To complete the DTNVSs’ features it incorporates built-in IR LED for close quarter missions with separate IR-ON indicator and low battery indicator in the field of view.

No external battery port – Why? The DTNVS uses standard CR123A batteries as commonly found in lasers or flashlights. A single battery provides over 25h run time. However, as the pods shut off when flipped up and therefore halve the power consumption, most users report up to 35h on a single battery.

Image Intensifier Tubes (IIT)Harder Gen3 White Phosphor
FinishMatte Black, Corrosion Resistant
Fibre re-enforces polycarbonate body
CapabilityFlip-Up On-Off
Side Flip-Up On-Off
Built-in IR LED with “IR-on” indicator in FOV
Low battery indicator in FOV
Waterproof: 20m (66ft) for 2 hours
Corrosion Resistance against salt water
Magnification1x
Diopter compensation-6 to +2 dpt
Battery Life25 h
Infrared illuminatoryes
StandardsExceeding MIL-STD-810G
True field of view40°
Close focus limit0.25 m to ∞
Power Supply1x CR123
Dimensions76 x 105 x 111 mm
Weight450 g
Included accessories
  • Hardcase
  • Molle pouch
  • Sacrificial lenses
  • Demist shields
  • Protective bikini covers
  • Rubber eye-cups
  • Objective lens caps
Included paperwork (original documentation is always included)
  • Tube specification sheet
  • Device birth certificate
  • Falconclaw user manual
  • Merchandise (patches, ACT lens cleaning paper)
  • Note! Flip the hardcase top cover foam to find everything above

Brand

ACT

Additional information

DTNVS LWT Gen3 WP Tube

0280D, 0281D, 0283D, 0284D
